Capacity and Parameters

1. Type: Inverter
2. TR (Ton Range): 1 Ton
3. (Btu/h): 12000
4. Rated Cooling Capacity (W): 3480 (500~3850)
5. EER (W/W): 3.05
6. Power Supply (Volt/Phase/Hz): 1/230/50HZ
7. Rated Power Input (W): 1140 (150~1550)
8. Rated Current (A): 5 (0.7~6.9)
9. Max. Current (A): 6.9
10. Indoor air flow (Hi/Mi/Lo) m3/h: 650
11. Compressor Type: Rotary
12. Refrigerant Type: R32
13. Refrigerant Standard (Kg): 0.6
14. Refrigerant Pipe Dia (mm) Liquid Side/Gas Side: 6/9
15. Evaporator/Condenser: 100% 7mm Grooved Copper
16. Heat Exchangers: Golden Fin
17. Indoor Noise Level (Hi/Mi/Lo) [dB(A)]: 41/38/35
18. Outdoor Noise Level [dB(A)]: 52

Air Flow Direction

1. Up & Down: Auto
2. Left & Right: Auto

Net Weight

1. Indoor (Kg): 10.0
2. Outdoor (Kg): 23.0

Net Dimension (WxDxH)

1. Indoor (W*D*H) mm: 805*200*292
2. Outdoor (W*D*H) mm: 700*245*544

Package Dimension (WxDxH)

1. Indoor (W*D*H)mm: 876*272*365
2. Outdoor (W*D*H)mm: 819*320*592

User Functions

1. Wifi: No
2. UVC Technology: No
3. Energy Saving: Yes (Up to 65%)
4. Dry Mode: Yes
5. Self Clean: Selfclean
6. ECO Mode: Yes
7. Turbo Function: Yes
8. Auto Restart Function: Yes
9. Sleep Mode: Yes
10. Low Noise: Yes
11. Timer: Yes
12. Quick & Easy Installation: Yes
13. Child Lock: Yes

Warranty

1. Compressor (Yrs): 12
2. Spare Parts and Components (Yrs): 4
3. Service (Yrs): 2 ​ ​𝐃𝐞𝐥𝐢𝐯𝐞𝐫𝐲 𝐍𝐨𝐭𝐞 : 𝐇𝐞𝐚𝐯𝐲 𝐢𝐭𝐞𝐦𝐬 𝐥𝐢𝐤𝐞 𝐀𝐂𝐬, 𝐅𝐫𝐢𝐝𝐠𝐞𝐬 and such home appliances 𝐰𝐢𝐥𝐥 𝐛𝐞 𝐝𝐞𝐥𝐢𝐯𝐞𝐫𝐞𝐝 𝐭𝐨 𝐭𝐡𝐞 𝐛𝐮𝐢𝐥𝐝𝐢𝐧𝐠 𝐠𝐚𝐭𝐞 𝐨𝐧𝐥𝐲, 𝐢𝐟 𝐚𝐜𝐜𝐞𝐬𝐬𝐢𝐛𝐥𝐞 𝐛𝐲 𝐯𝐞𝐡𝐢𝐜𝐥𝐞. An Extra Charge of BDT 300/- will be applied 𝐭𝐨 𝐜𝐚𝐫𝐫𝐲 per 𝐢𝐭𝐞𝐦 𝐭𝐨 𝐮𝐩𝐩𝐞𝐫 𝐟𝐥𝐨𝐨𝐫𝐬, if the customer wishes.
